j44.png1 #2 #3# reforming unit in aromatics Department of a Petrochemical Company


Customer Name: a Petrochemical Company

Problems existing in the project: according to UOP design, metal wound gasket has been used for the inlet and outlet pipeline flange of reforming reactor of 1 × 2 × 2 × reforming unit of a petrochemical aromatics department, and the flange port has not been insulated. After a period of operation, especially when the generation process is unstable, the temperature and pressure will fluctuate, and the inlet and outlet pipeline flange of reforming reactor installed with metal wound gasket will leak leak

Operating conditions:

Medium: hydrogen hydrocarbon

Application: inlet and outlet pipe flange of reforming reactor of 1 # 2# reforming unit in aromatics Department of a Petrochemical Company

Working temperature: 538 ℃

Working pressure: 0.84 MPa

Solution: after many technical exchanges and the evaluation of experts from aromatics department, the bmcmcmc high-performance graphite sealing gasket independently developed by BMC in Suzhou was officially installed and used during the maintenance period, and it has been running well since the successful start-up.

Product advantages:

With super leakage proof function

Safe and reliable sealing performance

Excellent thermal shock resistance

Strong resistance to alternating load

High temperature resistance

Constant sealing stress
